Netafim NCZ Kit 1″ Valve Pressure Regulator & Screen Filter 50 PSI

You need to be registered to see the prices

LOWEST PRESSURE LOSS IN THE INDUSTRY
Get more zone control for your money with smaller units and less units required for higher flows.

100% COMPATIBLE WITH ALL 2-WIRE CONTROLLERS
Save installation costs and get peace of mind with this completely 2-Wire compatible model. Inrush and holding currents are 50-60% lower than the industry average allowing the industry’s longest wire runs from valve to controller.

EFFICIENT FILTRATION
Nylon screen collects debris for efficient filtration and non-corrosive materials are resistant to chemicals and fertilizers.

IDEAL DRIP ZONE PRESSURE REGULATION
Achieve maximum hydraulic performance with higher pressure outputs designed to deliver the longest run lengths.

APPLICATIONS:
• Designed for all dripline, point source and micro-spray zones
• Residential or commercial landscape irrigation applications
• For zones between 0.5 and 30 GPM

SKU: 17700 Category: Tag:
Netafim Logo

Description

Netafim NCZ KIT 1″ WIDE SCREEN 50 PSI
Part number: NCZ-1S

Includes the following:
• 1” VALVE
• 1” WIDE RANGE PRESSURE REGULATOR
• 1” SCREEN FILTER

SPECIFICATIONS:
• Flow Range: 0.5 – 30 GPM
• Regulated pressure: 50 psi
• Maximum pressure: 140 psi
• Screen Filter mesh: 155
SERIES 80 VALVE MATERIALS:
• Glass reinforced polyamide body, bonnet and seat; Buna-N rubber diaphragm; Stainless steel 304 nuts, bolts and washer; Stainless Steel ANSI 302 spring
SCREEN FILTER MATERIALS:
• Polypropylene body; nylon screen; EPDM rubber o-rings
WIDE RANGE PRESSURE REGULATOR (WRPR) MATERIALS:
• ABS Plastic body/valve; PVC threads; stainless steel spring; EPDM diaphragm

Netafim Control Zones NCZ-1S

Additional information

Weight 2 lbs
Dimensions 13.25 × 7.5 × 3.2 in

Brand

Netafim
